6 Related Parameters
36 YASKAWA ELECTRIC TOBP C730600 75B YASKAWA AC Drive Option PG-B3 Installation Manual
F1-05
(384)
<3>
PG 1 Rotation
Selection
0: Pulse A leads
1: Pulse B leads
V/f w/ PG
CLV
AOLV
Default:
<1>
Range: 0, 1
F1-06
(385)
<3>
PG 1 Division
Rate for Pulse
Mon
Sets the division ratio for PG encoder pulse output.
Set as a three-digit number: x is the first digit, y is the
second digit, and z is the third digit:
When only the A pulse is read, this ratio is disabled
and pulses are set as 1/32 : 1.
V/f w/ PG
CLV
AOLV
Default: 1
Min: 1
Max: 132
F1-08
(387)
Overspeed
Detection Level
Sets the level for detecting overspeed (oS) as a
percentage of the maximum output frequency.
V/f w/ PG
CLV
AOLV
Default: 115
Min: 0
Max: 120
F1-09
(388)
Overspeed
Detection Delay
Time
Sets the time required for the motor to exceed the
level set in F1-08 to trigger a fault (oS).
V/f w/ PG
CLV
AOLV
Default:
<4>
Min: 0.0
Max: 2.0
F1-10
(389)
Speed Deviation
Detection Level
Sets the degree of speed deviation to trigger a dEv
fault. Set as a percentage of the maximum output
frequency.
V/f w/ PG
CLV
AOLV
Default: 10
Min: 0
Max: 50
F1-11
(38A)
Speed Deviation
Detect Delay
Time
Sets the time required for a speed deviation situation
to trigger a fault.
V/f w/ PG
CLV
AOLV
Default: 0.5
Min: 0.0
Max: 10.0
F1-12
(38B)
<3> <5>
PG 1 Gear Teeth
1
Number of gear teeth between the PG and motor.
A gear ratio of 1 will be used if any of these
parameters is set to 0.
V/f w/ PG
Default: 0
Min: 0
Max: 1000
F1-13
(38C)
<3> <5>
PG 1 Gear Teeth
2
F1-14
(38D)
PG
Open-Circuit
Detection Time
Sets the time in seconds for PG encoder disconnect to
be detected.
Note: An ov or oC error may occur depending on
motor speed and load conditions.
V/f w/ PG
CLV
AOLV
Default: 2.0
Min: 0.0
Max: 10.0
F1-21
(3BC)
<3>
PG 1 Signal
Selection
0: A pulse detection
1: AB pulse detection
V/f w/ PG
Default: 0
Range: 0, 1
F1-30
(3AA)
<6>
Motor 2 PG
Option Port
Selection
Selects the PG option connector for motor 2.
0: CN5-C
1: CN5-B
V/f w/ PG
CLV
Default: 1
Range: 0, 1
F1-31
(3B0)
<2> <7>
PG 2 Pulses per
Revolution
Sets the number encoder number of pulses per
revolution.
V/f w/ PG
CLV
Default: 1024
Min: 0
Max: 60000
F1-32
(3B1)
<7>
PG 2 Rotation
0: Pulse A leads
1: Pulse B leads
V/f w/ PG
CLV
Default: 0
Range: 0, 1
No.
(Addr. Hex)
Name Description
Control
Method
Values
Ratio =
(1 + x)
yz
Pulses × 60
F1-01
×
F1-13 (load side)
F1-12 (motor side)
