12 YASKAWA ELECTRIC TOBP C730600 24D 1000-Series Option SI-S3/V, SI-S3/T Installation Manual
4 CANopen Option Components
4 CANopen Option Components
◆ CANopen Option
Figure 2
Figure 2 Option Unit
A – LED (RUN)
<1> G – Function Earth wire connection (FE)
B – LED (ERR)
<1> H – Mounting clip
C – Option cover I – Wire
<2>
<1> Refer to CANopen Option Status LEDs on page 15 for details on the LEDs.
<2> Wires are not connected to the CANopen Option and are packaged separately in the box.
D – CANopen PCB J – Through-hole for wire
E – Attachment screw
hole for option cover
K – Communication cable connector
(9 pin D-sub)
F – Nameplate L – Option board connector
RUN
ERR
A
B
C
CANopen with cover attached
L
H
E
D
H
G
I
J
CANopen with cover removed
underside
F
K
FE
