6 Related Parameters
6 Related Parameters
The following parameters are used to set up the drive for operation with the option.
Confirm proper setting of the all parameters in Table 5 before starting network
communications.
Table 5 Related Parameters
No. Name Description Values
b1-01
<1>
Frequency Reference
Selection
Selects the frequency reference input source
0: Operator - Digital preset speed d1-01 to d1-17
1: Terminals - Analog input terminal A1 or A2
2: MEMOBUS/Modbus communications
3: Option Card
4: Pulse Input (Terminal RP)
Default:
<2>
Range: 0 to 4
b1-02
<1>
Run Command Selection
Selects the run command input source
0: Digital Operator - RUN and STOP keys
1: Digital input terminals S
2: MEMOBUS/Modbus communications
3: Option Card
Default: 1
Range: 0 to 3
E2-04
<3>
Motor 1 Motor Poles
Set the number of motor poles described on the
motor nameplate.
Default: 4
Min: 2
Max: 48
F6-01
Operation Selection after
Communications Error
Determines drive response when a bUS error is
detected during communications with the
CANopen Option
0: Ramp to Stop
1: Coast to Stop
2: Fast-Stop
3: Alarm Only
<4>
Default: 1
Range: 0 to 3
F6-02
External Fault Detection
Conditions (EF0)
Sets the condition for external fault detection
(EF0)
0: Always detected
1: Detected only during operation
Default: 0
Range: 0, 1
F6-03
Stopping Method for
External Fault from
Communication Option
Board
Determines drive response for external fault input
(EF0) detection during CANopen communication
0: Ramp to Stop
1: Coast to Stop
2: Fast-Stop
3: Alarm Only
<4>
Default: 1
Range: 0 to 3
F6-07
<5>
NetRef/ComRef Selection
Function
0: Multi-step speed reference disabled (F7 mode)
1: Multi-step speed reference allowed (V7 mode)
Default: 1
Range: 0, 1
