1-3

163475-1CD

MHTH Postioner

SIGMA V

1 Introduction

1.2 Overview

1.2.4 Dimensions

Fig. 1-2: Dimensions

440 mm

434 mm

595 mm

CENTER OF GRAVITY

MASS = 293.7 kg

169679 MHTH Drive Module

598.4 mm

456 mm

288 mm

256 mm

53 mm

280 mm

560 mm

391 mm

169680 MHTH Drive Assembly

10/28
