YASKAWA SMG Series

2.2 Installation
21
Gear Ratio (Varies with Gear Type.)
Code Specification SGMG SGMS
A 1/6 S, T*
B 1/11 S, T
C 1/21 S, T
1 1/5 L L
2 1/9 L L
5 1/20 L* L
7 1/29 or 1/33 L, S, T* L*
8 1/45 L* L*
* Not all applicable models available.
Shaft Specifications (Varies with Gear Type.)
Code Specification SGMG SGMS
K Straight, with key L L
R Straight, with key and tap S, T
2
