User Constant Tables
5-11
* 0 or 1 for flux vector control.
b1-05
Operation
selection for
setting E1-
09 or less
Used to set the method of
operation when the fre-
quency reference input is
less than the minimum out-
put frequency (E1-09).
0: Run at frequency refer-
ence (E1-09 not effec-
tive).
1: STOP (Frequencies
below E1-09 in the coast
to stop state.)
2: Run at min. frequency.
(E1-09)
3: Run at zero-speed (Fre-
quencies below E1-09 are
zero)
0 to 3 0 No No No No A 184H 6-17
b1-06
Read
sequence
input twice
Used to set the responsive-
ness of the control inputs
(forward/reverse and multi-
function inputs.)
0: Two scans every 2 ms
(Use for fast responses.)
1: Two scans every 5 ms
(Use for possible
malfunction due to
noise.)
0 or 1 1 No A A A A 185H -
b1-07
Operation
selection
after switch-
ing to
remote
mode
Used to set the operation
mode by switching to the
Remote mode using the
Local/Remote Key.
0: Run signals that are input
during mode switching
are disregarded. (Input
Run signals after
switching the mode.)
1: Run signals become
effective immediately
after switching to the
Remote mode.
0 or 1 0 No A A A A 186H -
b1-08
Run Com-
mand selec-
tion in
program-
ming modes
Used to set an operation
interlock in programming
modes.
0: Cannot operate.
1: Can operate (Disabled
when Digital Operator is
set to select Run Com-
mand (when b1-02 = 0)).
0 to 1
0 No A A A A 187H -
0 to 2
Con-
stant
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO
BUS
Regis-
ter
Page
V/f
V/f
with
PG
Open
Loop
Vec-
tor
Flux
Vec-
tor
2: Cannot operate. (Cannot
be in programming mode
during operation.)
To Next Page
