YASKAWA Varispeed f7 User Manual

User Constant Tables
5-45
 Terminal Function Constants: H
The following settings are made with the terminal function constants (H constants): Settings for external ter-
minal functions.
Multi-function Contact Inputs: H1
User constants for multi-function contact inputs are shown in the following tables.
* The values in parentheses indicate factory settings when initialized in 3-wire sequence.
Multi-function Contact Input Functions
Con-
stant
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO
BUS
Regis-
ter
Page
V/f
V/f
with
PG
Open
Loop
Vec-
tor
Flux
Vec-
tor
H1-01
Terminal S3
function
selection
Multi-function contact input
1
0 to 78 24 No A A A A 400H -
H1-02
Terminal S4
function
selection
Multi-function contact input
2
0 to768 14 No A A A A 401H -
H1-03
Terminal S5
function
selection
Multi-function contact input
3
0 to78
3 (0)
*
NoAAAA402H-
H1-04
Terminal S6
function
selection
Multi-function contact input
4
0 to 78
4 (3)
*
NoAAAA403H-
H1-05
Terminal S7
function
selection
Multi-function contact input
5
0 to 78
6 (4)
*
NoAAAA404H-
H1-06
Terminal S8
function
selection
Multi-function contact input
6
0 to 78
8 (6)
*
No A A A A 4-5H -
Set-
ting
Value
Function
Control Methods
Page
V/f
V/f
with
PG
Open
Loop
Vec-
tor
Flux
Vec-
tor
0 3-wire sequence (Forward/Reverse Run Command) Yes Yes Yes Yes 6-16
1 Local/Remote selection (ON: Operator, OFF: Constant setting) Yes Yes Yes Yes 6-78
2 Option/Inverter selection (ON: Option board) Yes Yes Yes Yes
6-85
6-163
3
Multi-step speed reference 1
When H3-09 is set to 2, this function is combined with the master/auxiliary
speed switch.
Yes Yes Yes Yes 6-10
4 Multi-step speed reference 2 Yes Yes Yes Yes 6-10
5 Multi-step speed reference 3 Yes Yes Yes Yes 6-10
6 Jog frequency command (higher priority than multi-step speed reference) Yes Yes Yes Yes 6-10
7 Accel/decel time 1 Yes Yes Yes Yes 6-26
8 External baseblock NO (NO contact: Baseblock at ON) Yes Yes Yes Yes 6-79
9 External baseblock NC (NC contact: Baseblock at OFF) Yes Yes Yes Yes 6-79
