Individual Functions
6-103
Note Communications error details are stored until an fault reset is input (you can also reset while the Unit is operating).
002CH
Inverter status
Bit 0
Operation 1: Operating
Bit 1
Zero-speed 1: Zero-speed
Bit 2
Frequency matching 1: Matched
Bit 3
User-defined speed matching 1: Matched
Bit 4
Frequency detection 1 1: Output frequency ≤ L4-01
Bit 5
Frequency detection 2 1: Output frequency ≥ L4-01
Bit 6
Inverter startup completed 1: Startup completed
Bit 7 Low voltage detection 1: Detected
Bit 8
Baseblock 1: Inverter output baseblock
Bit 9
Frequency reference mode 1: Not communications 0: Communications
Bit A
Run Command mode 1: Not communications 0: Communications
Bit B
Overtorque detection 1: Detected
Bit C
Frequency reference lost 1: Lost
Bit D Retrying error 1: Retrying
Bit E Error (including MEMOBUS communications time-out) 1:Error occurred
Bit F MEMOBUS communications time-out 1: Timed out
002DH
Multi-function contact output status
Bit 0 Multi-function contact output (terminal M1-M2) 1: ON 0: OFF
Bit 1 Multi-function PHC output 1 (terminal P1 - PC) 1: ON 0: OFF
Bit 2 Multi-function PHC output 2 (terminal P2 - PC) 1: ON 0: OFF
Bits 3 to F Not used
002EH - 0030H Not used
0031H Main circuit DC voltage
0032H Torque monitor
0033H Output power (U1-08)
0034H - 0037H Not used
0038H PID feedback quantity (Input equivalent to 100%/Max. output frequency; 10/1%; without sign)
0039H PID input quantity (±100%/±Max. output frequency; 10/1%; with sign)
003AH PID output quantity (±100%/±Max. output frequency; 10/1%; with sign)
003BH CPU software number
003CH Flash software number
003DH
Communications error details
Bit 0 CRC error
Bit 1 Invalid data length
Bit 2 Not used
Bit 3 Parity error
Bit 4 Overrun error
Bit 5 Framing error
Bit 6 Time-out
Bits 7 to F Not used
003EH kVA setting
003FH Control method
Register No. Contents
