10-12
.
îš„Interrupting Rating
Varispeed F7 is suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical
amperes, 240 VAC maximum (200 V Class) and 480 VAC maximum (400 V Class).
Use a circuit breaker or fuses having an interrupting rating not less than 100,000 RMS symmetrical amperes,
600 VAC maximum.
îš„Motor Overheat Protection
To protect the motor from overheating, set the E2-01 constant in the Inverter to the same value as the level of
the motor rated current.
Table 10.3 Power Supply for Control Circuits
Input/Output Terminal Power Supply
Open Collec-
tor Outputs
P1, P2, PC Class 2 power supply
Digital Inputs
S1, S2, S3, S4,
S5, S6, S7, ,
SC
LVLC power supply when using
internal power supply. Class 2
power supply when using exter-
nal power supply.
Analog Inputs
RP, +V, , A1,
A2, , AC
S8
-V
A3
To Next Page
