10-18
Fig 10.8 Installation Method for Filter and Inverter (CIMR-2022 to 2110, 4022 to 4300)
PE
IM
Remove the paint on the ground side.
Inverter
Inputs
Filter
Outputs
Wiring length: 20 m max.
Remove the paint on the ground side.
Wiring length:
40 cm max.
Metallic plate
R/L1, S/L2, T/L3
R/L1, S/L2, T/L3
U/T1, V/T2, W/T3
