Yealink SIP-T29G User Manual

Customizing Your Phone
93
Page Tips
You can use page tips feature to enable the page icon and page switch key LED to indicate
different statuses. This feature is disabled by default.
The following table lists the page icons to indicate different statuses:
Icons
Description
Fast flashing: the BLF monitored user receives an incoming call on
the non-current page.
Solid: there is a parked call on the non-current page.
Fast flashing: the line receives an incoming call on the
non-current page.
For more information on the page switch key LED status, refer to LED Instructions on page 9.
To configure the page icon to indicate status via web user interface:
1. Click on Dsskey->Line key.
2. Select Enabled from the pull-down list of Enable Page Tips.
3. Click Confirm to accept the change.
Label Length
You can specify labels for some key features, which will be displayed on the idle LCD screen. If
the length of the label exceeds the maximum display length, the phone only displays the first
few characters. You can configure the phone to display more characters via label length feature.
1
1

Yealink SIP-T29G Specifications

General

Speakerphone	Yes
Voice codecs	G.711, G.722, G.723, G.726, G.729ab, iLBC
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Lines quantity	10 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Power over Ethernet (PoE)	-
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800
Volume control	Buttons

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
