User Guide for the SIP-T29G IP Phone
118
Using the speakerphone
Using the headset
You can also dial the number first, and then choose the way you want to speak to the other
party.
You can also search and dial a contact from call history, local directory or remote phone book.
For more information, refer to Contact Management on page 62 and Call History Management
on page 80.
During a call, you can alternate between Speakerphone, Headset, and Handset modes by
pressing the Speakerphone key, the HEADSET key, or by picking up the handset.
The call duration of the active call and far-site’s information (name or phone number) are visible
on the LCD screen. In the figure below, the call to “Tom” (the phone number: 1023) has lasted 6
seconds.
To place a call using the handset:
1. Pick up the handset.
2. Enter the desired number using the keypad.
3. Press , , or the Send soft key.
The # key is configured as a send key by default. You can also set the * key as the send key, or
set neither. For more information, refer to the Key As Send on page 53.
Note
To place a call using the hands-free speakerphone mode:
Do one of the following:
- With the handset on-hook, press or the line key to obtain a dial tone.
Enter the desired number using the keypad.
Press , or the Send soft key.
You can also dial using the SIP URI or IP address. To obtain the IP address of a phone, press the
OK key when the phone is idle. The maximum length of SIP URI or IP address length is 32
characters. For example, SIP URI: 3606@sip.com, IP: 192.168.1.15.
Your phone may not support direct IP dialing. Contact your system administrator for more
information.
