Yealink SIP-T46G Guide

User Guide SIP-T46G IP Phone
44
4. Press the Save soft key to accept the change or the Back soft key to cancel.
To configure the BroadSoft phonebook via web user interface:
1. Click on Contacts->BroadSoft.
2. Select the desired BroadSoft item from the pull-down list of BroadSoft Item.
3. Enter the parameters: display name, server address, port, username and password
in the corresponding fields.
4. Click Confirm to accept the change.
To access the Broadsoft directory via phone user interface:
1. Press Directory->BroadSoft.
2. Select the desired directory item, and then press the Enter soft key.
The phone connects to load the BroadSoft directory, and then displays the desired
BroadSoft contact list on the LCD screen.
3. Press the Back soft key to back to the previous interface.
To place a call from the Broadsoft directory:
1. Press Directory->BroadSoft.
2. Select the desired directory item, and then press the Enter soft key to load the
BroadSoft directory.
3. Select the desired contact in the BroadSoft directory.
4. Press the Dial soft key.

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
