Yealink SIP-T46S User Manual

Basic Call Features
153
Picking Up a Call in the Group
Procedure:
1. Pick up the handset, press the line key or the Speakerphone key.
The GPickup appears on the LCD screen.
2. Press GPickup on your phone when any phone in the group receives an incoming call.
The call is answered on your phone.
You can also use a Group Pickup key (refer to Configuring a Group Pickup Key) to pick up a call
directly.
Note
Anonymous Call
Anonymous call, which is configurable on a per-line basis, allows you to place a call to someone
without revealing your identification by blocking your name or phone number from being
displayed on the called party’s phone screen. You can also configure the phone to send
anonymous call on/off code to the server to activate/deactivate anonymous call on the server
side.
Note
Configuring the Anonymous Call
Procedure:
1. Navigate to Menu->Features->Anonymous.
For the SIP-T42S/T42G/T41S/T41P/T40G/T40P IP phone, navigate to
Anonymous call is not available on all servers. Contact your system administrator for the
anonymous call on code and off code.
The directed call pickup code and group call pickup code are predefined by your system
administrator on the system server.
The call pickup code configured on a per-line basis takes precedence over that configured on a
global basis.
Downloaded from ManualsNet.com search engine

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
