Yealink SIP-T46S User Manual

User Guide for T4 Series IP Phones
154
Menu->Features->Anonymous Call.
2. Select a desired line.
For the SIP-T42S/T42G/T41S/T41P/T40G/T40P IP phone, select a desired line from the Line
ID field.
3. Select Enabled from the Local Anonymous field.
For the SIP-T48S/T48G IP phone, tap the On radio box of the Local Anonymous field.
4. (Optional.) Select the desired value from the Send Anony Code (Send Anonymous Code)
field.
5. (Optional.) Enter the anonymous call on code and off code respectively in the On Code and
Off Code field.
The phone will send the configured on code or off code depending on your selection when
you enable or disable anonymous call feature on the phone.
6. Press Save.
Anonymous call is configurable via web user interface at the path Account->Basic.
Placing an Anonymous Call
Procedure:
1. Using the specific line which has been configured with anonymous call feature to place a
call to phone B.
The LCD screen of phone B prompts an incoming call from anonymity.
Downloaded from ManualsNet.com search engine

Yealink SIP-T46S Specifications

General

Manual	Yes
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	CNG, G.711Mu, G.711a, G.722, G.723.1, G.726, G.729ab, VAD, iLBC
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	16
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
AC adapter input voltage	100 - 240 V
AC adapter output current	2 A
AC adapter output voltage	5 V
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
Volume control	Digital
Number of programmable keys	10
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	SIP v1, SIP v2, LLDP/CDP/DHCP, OpenVPN, IEEE802.1X, IPv6, FTP/TFTP/HTTP/HTTPS
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	213 mm
Width	244 mm
Height	185 mm
Package depth	255 mm
Package width	274 mm
Package height	128 mm
