Overview
11
Icon
Description
T48S/T48G
T46S/T46G
The call on shared line is placed
on public hold.
(Local SCA Phone)
(Monitoring SCA
Phone)
(Local SCA Phone)
(Monitoring SCA
Phone)
The call on shared line is placed
on private hold.
The call on shared line is barged
in by the other shared line party.
In a multi-party call, all the
participants place the call on hold.
Icon indicators (associated with a bridged line)
The Local BLA Phone is involved in a BLA call, while the Monitoring BLA Phone is not involved in
a BLA call and used for monitoring bridged line.
Icon
Description
T48S/T48G
T46S/T46G
The bridged line is idle.
(Monitoring BLA
Phone)
(Monitoring BLA
Phone)
The bridged line is seized.
(Flashing)
The bridged line receives an incoming
call.
(Flashing)
The bridged line is dialing.
The bridged line is busy or is in a call.
The call on bridged line is placed on
hold.
