Yealink T27P Administrator's Guide

Appendix
601
in which User B has enabled no answer call forward. The incoming call is forwarded to
User C when User B does not answer the incoming call after a period of time. In this call
flow scenario, the end users are User A, User B, and User C. They are all using Yealink
SIP IP phones, which are connected via an IP network.
The call flow scenario is as follows:
1. User B enables no answer call forward, and the destination number is User C.
2. User A calls User B.
3. User B does not answer the incoming call.
4. User B forwards the incoming call to User C.
5. User C answers the call.
Call is established between User A and User C.
User A Proxy Server User B User C
F1. INVITE B
F2. INVITE B
F3. 180 Ringing
F8. ACK
F9. INVITE C
F10. INVITE C
F11. 180 Ringing
F12. 180 Ringing
F13. 200 OK
F14. 200 OK
F15. ACK
F16. ACK
F4. 180 Ringing
F5. 302 Move Temporarily
F6. ACK
F7. 302 Move Temporarily
2-way RTP channel established
Step
Action
Description
F1
INVITE—User A to Proxy
Server
User A sends the INVITE message to a
proxy server. The INVITE request is an
invitation to User B to participate in a

Yealink T27P Specifications

General

Wall Mountable	Yes
Local Phonebook	1000 entries
Bluetooth	No
Wi-Fi	No
Gigabit Ethernet	No
Display	3.66" 240x120 pixel graphical LCD with backlight
Audio Features	HD voice, Full-duplex speakerphone
Network	Dual-port 10/100 Ethernet switch
Protocols	SIP v1 (RFC2543), v2 (RFC3261)
Power	IEEE 802.3af PoE
Connectivity	2 x RJ45 10/100M Ethernet ports
Voice Codecs	G.711(A/μ), G.722, G.723, G.729AB, G.726
EHS	Supports EHS with Plantronics headsets
Headset Port	Yes
Power Adapter	5V DC (optional)
