Yealink T27P Administrator's Guide

Configuring Basic Features
159
At least one item should be selected to be imported into the local directory.
7. Click Import to complete importing the contact list.
To export a contact list via web user interface:
1. Click on Directory->Local Directory.
2. Click Export XML (or Export CSV).
3. Click Save to save the contact list to your local system.
To add a contact to the local directory via phone user interface:
1. Press Menu->Directory->Local Directory.
2. Select the desired contact group and then press the Enter soft key.
3. Press the Add soft key.
4. Enter the name and the office, mobile or other numbers in the corresponding fields.
5. Press or , or the Switch soft key to select the desired account from the
Account field.
If Auto is selected, the IP phone will use the first available account when placing
calls to the contact from the local directory.
6. Press or , or the Switch soft key to select the desired ring tone from the
Ring field.
7. Press the Save soft key to accept the change.
Live dialpad allows IP phones to automatically dial out the entered phone number after
a specified period of time.

Yealink T27P Specifications

General

Wall Mountable	Yes
Local Phonebook	1000 entries
Bluetooth	No
Wi-Fi	No
Gigabit Ethernet	No
Display	3.66" 240x120 pixel graphical LCD with backlight
Audio Features	HD voice, Full-duplex speakerphone
Network	Dual-port 10/100 Ethernet switch
Protocols	SIP v1 (RFC2543), v2 (RFC3261)
Power	IEEE 802.3af PoE
Connectivity	2 x RJ45 10/100M Ethernet ports
Voice Codecs	G.711(A/μ), G.722, G.723, G.729AB, G.726
EHS	Supports EHS with Plantronics headsets
Headset Port	Yes
Power Adapter	5V DC (optional)
