Yealink T27P Administrator's Guide

Configuring Basic Features
73
For SIP-T27P/T23P/T23G/T21(P) E2:
The default value is 30.
Web User Interface:
Settings->Preference->Backlight Time (seconds)
Phone User Interface:
Menu->Settings->Basic Settings->Display->Backlight->Backlight Time
To configure backlight via web user interface (take SIP-T23G IP phones for example):
1. Click on Settings->Preference.
2. Select the desired value from the pull-down list of Backlight Time (seconds).
3. Click Confirm to accept the change.
To configure backlight via phone user interface (take SIP-T23G IP phones for example):
1. Press Menu->Settings->Basic Settings->Display->Backlight.
2. Press or , or the Switch soft key to select the desired type from the
Backlight Time field.
3. Press the Save soft key to accept the change.
To configure the backlight via web user interface (take SIP-T46G IP phones for example):
1. Click on Settings->Preference.
2. Select the desired value from the pull-down list of Backlight Inactive Level.
3. Select the desired value from the pull-down list of Backlight Active Level.

Yealink T27P Specifications

General

Wall Mountable	Yes
Local Phonebook	1000 entries
Bluetooth	No
Wi-Fi	No
Gigabit Ethernet	No
Display	3.66" 240x120 pixel graphical LCD with backlight
Audio Features	HD voice, Full-duplex speakerphone
Network	Dual-port 10/100 Ethernet switch
Protocols	SIP v1 (RFC2543), v2 (RFC3261)
Power	IEEE 802.3af PoE
Connectivity	2 x RJ45 10/100M Ethernet ports
Voice Codecs	G.711(A/μ), G.722, G.723, G.729AB, G.726
EHS	Supports EHS with Plantronics headsets
Headset Port	Yes
Power Adapter	5V DC (optional)
