Yealink W60B User Manual

11
Quick Start Guide
DECT IP Phone – W60B & W56H
CALL HOLD AND RESUME
To place a call on hold:
Press the Options soft key during a call, and then select Hold.
To resume a call, do one of the following:
• If there is only a call on hold, press the Resume soft key.
• If there are two calls on hold, press the Resume soft key to resume the current call.
Press the Swap soft key to swap between calls.
CALL TRANSFER
You can transfer a call in the following ways:
Blind Transfer
1. Press the Options soft key during a call, and then select Transfer.
2. Enter the number you want to transfer the call to.
3. Press the Transfer soft key.
Semi-Attended Transfer
1. Press the Options soft key during a call, and then select Transfer.
2. Enter the number you want to transfer the call to.
3. Press ， or to dial out.
4. Press the Transfer soft key when you hear the ring-back tone.
Attended Transfer
1. Press the Options soft key during a call, and then select Transfer.
2. Enter the number you want to transfer the call to.
3. Press ， or to dial out.
4. Press the Transfer soft key after the call is answered.
CALL FORWARD
To enable the call forward feature on a specific line:
1. Press the OK key to enter the main menu, and then select Call Features->Call Forward.
2. Press or to highlight the desired line, and then press the OK soft key.
3. Press or to highlight the desired forwarding type, and then press the OK soft key.
Always----Incoming calls are forwarded immediately.
Busy----Incoming calls are forwarded when the line is busy.
No Answer----Incoming calls are forwarded if not answered after a period of time.
4. Select Enabled from the Status field.
5. Enter the number you want to forward the incoming calls to in the Target field.
For No Answer Forward, press or to select the desired ring time to wait before forwarding in the
After Ring Time field.
6. Press the Save soft key to accept the change.

Yealink W60B Specifications

General

Dimensions	130mm x 100mm x 25.1mm
Operating Temperature	0°C to +40°C
DECT Standards	CAT-iq 2.0
Number of Handsets	Up to 8
Internal Calls	Yes
External Calls	Yes
Call Hold	Yes
Call Transfer	Yes
3-way Conference	Yes
Call Waiting	Yes
Mute	Yes
Redial	Yes
DECT Radio Coverage	Up to 50m indoors, 300m outdoors
PoE	IEEE 802.3af Class 1
Configuration	Browser/phone/auto-provision
Wall Mountable	Yes
Wireless Technology	DECT
Channels	120
Concurrent Calls	Up to 8 concurrent calls
Audio Codecs	G.722, G.711, G.729, G.726, iLBC, Opus
Security	TLS, SRTP, HTTPS, 802.1X
Operating Humidity	10 ~ 95%
Handset Registration	8 handsets
Frequency Bands	1880-1900 MHz
Operating Range	Up to 50m indoors, 300m outdoors
Humidity	10-95%
Compliance	CE, FCC, RCM
Network Protocols	SIP, HTTP, HTTPS, DHCP, DNS, NTP, STUN
Number of SIP Accounts	Up to 8 SIP accounts
Storage Temperature	-30°C to +70°C
