NeoGate TE100 Administrator Guide
www.yeastar.com Page 6
2. System setup
2.1 Connection Drawing
2.2 Connecting Ethernet Line
TE100 provides two 10/100Mbps Ethernet ports with RJ45 interface and LED indicator.
Plug Ethernet line into TE100‟s Ethernet port, and then connect the other end of the
Ethernet line with a hub, switch, router, LAN or WAN. Once connected, check the status
of the LED indicator. A yellow LED indicates the port is in the connection process, and a
green LED indicates the port is properly connected.
2.3 Supplying Power
Please follow the steps below to connect the TE100 unit to a power outlet:
1. Connect the small end of the power cable to the power input port on the TE100
back panel, and plug the other end of the cable into a 100V~240V AC power
outlet.
2. Check the Power LED on the front panel. A solid green LED indicates that power is
being supplied correctly.
