4. Status
Click to start to check the status of TE100, including the system‟s status and the
detailed reports
4.1 System Status
In this page, we can check the status of the system, including trunk status, network
status and system information.
4.1.1 Trunk status
Figure 4-1
Trunks:
VoIP Trunk:
Status
Unregistered: Trunk registration failed.
Registered: Successful registration, trunk is ready for use.
Request Sent: Registering.
Waiting: Waiting for authentication.
Service Provider:
Status
OK: Successful registration, trunk is ready for use.
Unreachable: The trunk is unreachable.
Failed: Trunk registration failed.
E1 Trunk:
Connect
Alarm
Comment
The port doesn‟t have E1 line connected.
E1 line has been connected to the port; PRI is in
corresponding or can‟t communicate.
Succeed.
