- 9 -
9. Funnel Set (5VY-A4460-70)
Parts List
CAUTION :
• The air cleaner case is kept fixed by the standard funnel. Remove this
standard funnel and install the plate in its destined place.
• Before installation, apply a thin coat of grease to the threads of the funnel
and plate.
• For standard setting, use funnel 5VY-14469-70 (the shorter one).
• Select the setting according to exhaust pipe specification, rider’s preference
and track layout.
No. PART No. PART NAME Q’TY REMARKS
5VY-14477-70 PLATE 2
5VY-14469-70 FUNNEL, 1 4 L=27 mm
5VY-14469-90 FUNNEL, 1 4 L=46 mm
