- 36 -
24. Footrest Set (5VY-C7400-70)
Parts List
No. PART No. PART NAME Q’TY REMARKS
1 5SL-27412-70 BRKT., 1 1
2 5VY-27452-70 BRKT., FOOTREST 1 1
* 3 90151-08022 SCREW 4
* 4 90109-085G6 BOLT 4
* 5 4JT-27411-20 FOOTREST 1 2
* 6 97007-06020 BOLT 2
* 7 92907-06600 WASHER, PLATE 2
* 8 5FL-27445-00 PLATE 1 1
* 9 92017-06012 BOLT, BUTTON HEAD 2
10 5PW-18111-71 PEDAL, SHIFT 1
11 5EB-18162-70 PEDAL, FRONT 2
* 12 98707-06020 SCREW, FLAT HEAD 2
13 5VY-18112-70 ARM, SHIFT 1
* 14 95824-06020 BOLT, FLANGE 1
* 15 92017-06020 BOLT, BUTTON HEAD 5
16 5VY-18115-70 ROD, SHIFT 1
* 17 3TC-18116-00 JT., ROD 1 1
* 18 95304-06700 NUT 1
* 19 3TC-18117-00 JT., ROD 2 1
* 20 90170-06228 NUT 1
* 21 92017-06025 BOLT, BUTTON HEAD 1
* 22 95607-06100 NUT, U 2
23 5VY-27422-70 BRKT., 2 1
24 5VY-27462-70 BRKT., FOOTREST 2 1
* 25 5SL-27446-00 PLATE 2 1
26 5SL-2745A-71 COLLAR 4
27 5VY-2741L-70 BRKT., 4 1
28 5EB-27211-70 PEDAL, BRAKE 1
* 29 5SL-27853-71 SHAFT, PEDAL 1 1
* 30 95307-08700 NUT 1
* 31 92907-06200 WASHER, PLAIN 1
32 91401-16012 PIN, SPRIT 1
* 33 5EB-27456-70 SPRING, RETURN 1
* 34 92017-08030 BOLT, BUTTON HEAD 2
* 35 95307-08700 NUT 2
To Next Page
