YEC ’04 YZF-R1 User Manual

- 2 -
2Kit Parts
2-1 Basic Kit Set Contents
Spark plug set
Head gasket (0.30 mm)
High lift camshaft (INT, EXT)
Valve spring set
Funnel set
AIS plug set
Clutch spring set
ACM rotor
Wire harness set
Engine control unit
Kit manual
Note:
The part marked [ * ] at the top of the parts list is included in the kit, but if it is
specifically needed, it is available from Yamaha authorized dealers.
2-2 Engine Parts
1. Maintenance set (5VY-MAINT-70)
Parts List
No. PART No. PART NAME Q’TY REMARKS
* 1 5VY-11181-00 GSKT., H/C 3
* 2 5VY-11351-00
GSKT, 1 3
* 3 5VY-11603-00
RING SET 12
* 4 5VY-1165A-01
BOLT, CON-ROD 12
* 5 90468-12069
CIRCLIP 12
* 6 4TV-12119-00
SEAL, STEM 36 INT
* 7 4SV-12119-00 SEAL, STEM 24 EXT
* 8 5VY-13414-00 GSKT, STRAINER 3
* 9 5VY-15451-00
GSKT COVER1 3 ACM
* 10 5VY-15461-00 GSKT COVER2 3 CLUTCH
* 11 5VY-15456-00 GSKT 1 3 PICK UP
* 12 5VY-15462-00 GSKT COVER3 3 BREATHER
* 13 90179-20007 NUT 3 CLUTCH BOSS
* 14 90215-30233 WASHER LOCK 3 SPROCKET
* 15 93102-40330 OIL SEAL 3 DRIVE AXLE
* 16 90110-06027 BOLT 9 MAIN AXLE
