26. Valve Seat Cutter Set
Parts List
This cutter set includes the same parts as for the 03 R6, but when using them for the
R1, reverse the respective names and locations for intake and exhaust.
The set includes an addition type of spindle in contrast with the assembly for the 03
R6.
No. PART No. PART NAME Q’TY REMARKS
1 5SL-92110-70 CUTTER, INT 1 1 27.0 × 60°
2 5SL-92110-80 CUTTER, INT 2 1 27.0 × 90°
3 5SL-92110-90 CUTTER, INT 3 1 27.0 × 120°
4 5SL-92120-70 CUTTER, EXT 1 1 25.0 × 60°
5 5SL-92120-80 CUTTER, EXT 2 1 25.0 × 90°
6 5SL-92120-90 CUTTER, EXT 3 1 25.0 × 120°
7 5SL-92101-70 SPINDLE 1 4,0 mm
8 5VY-92101-70 SPINDLE 1 4,5 mm
