YEC ’04 YZF-R1 User Manual

- 26 -
16. Chasis Protector Set (5VY-C117G-70)
Parts List
Remove the bolt holding the head and using the bolt supplied, install the chassis
protector and cut the cowling to fit the vehicle.
17. Rear Suspension Spring
Parts List
This spring is intended for use in the standard shock absorber.
Specification
No. PART No. PART NAME Q’TY REMARKS
1 5VY-2117G-70 PROTECTOR 2
2 5SL-21472-70 COLLAR, PROTECTOR LH. 1
3 5SL-21477-70 COLLAR, PROTECTOR RH. 1
* 4 91317-10070 BOLT, HEX. SOCKET 2
* 5 90201-105R9 WASHER 2
No. PART No. PART NAME Q’TY REMARKS
1 5VY-22212-70 SPRING, 1 K=9.0 kgf/mm
KIT STD
Free length 174 mm 174 mm
Spring rate 9,0 kgf/mm 8,5 kgf/mm
External colour Yellow Silver
FWD
FRAME
ENGINE
RIGHT
LEFT
FRAME
