- 19 -
<Operation Procedure for Initialization of Adjustment Values>
Item Operation Meter display Significance
(Items and their operating procedures are the same as <Operating procedure for F1 to FD fuel volume/ignition timing
adjustment>
i
Determine Applicable item
(Code FE)
After selecting FE in above, keep
"RESET" and "SELECT"
simultaneously pressed.
[FE___*] Number of changes in adjustment
values for F1 to FD appears in lower
figure place in LC: Mode for checking
the number of adjustment values to
be operated. Holding "RESET" and
"SELECT" simultaneously pressed
allows transfer to Select ECU
applicable item.
j
Check number of
adjustment values to be
operated/initialise
adjustment value.
Switch is possible by pressing
"SELECT" or "RESET".
[FE__88] "88" appears in lower-figure place in
LC: Initialisation mode for adjustment
value Pressing "SELECT" or
"RESET" alternately changes the
mode either for checking the number
of values to be operated, or for
initialisation.
k
Initialisation of Changed
Adjustment Values
(Initialisation mode being
selected)
Keep "RESET" and "SELECT"
simultaneously pressed.
(for 2 sec. or more)
[FE___0] The lower area of LC displays (0) to
indicate the completion of
initialisation.
l
Initialisation ends After ceasing the simultaneous
pressing of "RESET" and "SELECT",
repeat the process
[FE____] Enter the state for selecting Code FE
(adjustment value management).
The rest of the procedure is the same
as the above, and the selection mode
for ECU applicable items starts with
"SELECT" or "RESET".
➔
➔
To Next Page
