- 24 -
WIRING DIAGRAM
SPEED SENSOR LEAD
ENGINE GROUND LEAD
FUEL PUMP LEAD
HANDLEBAR SWITCH (RIGHT), METER LEAD, HEADLIGHT HARNESS
HANDLEBAR SWITCH (RIGHT)
IGNITION COIL CONNECTOR
HEADLIGHT HARNESS CONNECTOR
CRANKSHAFT SENSOR LEAD
ECU
MAIN SWITCH, SELECTOR SWITCH LEAD
ENGINE KILL SWITCH LEAD
OIL LEVEL GAUGE LEAD
ACM LEAD
STARTER MOTOR LEAD
NEGATIVE BATTERY LEAD
STARTING SAFETY RELAY
EXTERNAL POWER CONNECTOR
HEADLIGHT HARNESS
ATMOSPHERIC PRESSURE SENSOR
ENGINE STOP SWITCH
MAIN FUSE
STARTER RELAY
HEADLIGHT CORD
POSITIVE BATTERY LEAD
FUSE BOX (REMOVE FLASHER RELAY)
EXUP LEAD
THROTTLE BODY LEAD
TAILLIGHT UNIT
PASS ON INSIDE OF BATTERY BAND
