- 32 -

Rear Wheel Attachment Set (4XV-C5310-80)

Parts List

No. PART No. PART NAME Q’TY REMARKS

1 4XV-25767-70 COLLAR, DISK BRAKE 1

2 5FL-93307-70 BEARING 4

3 4XV-25317-80 SPACER, BEARING 1

4 4XV-2582V-80 DISK, BRAKE 1

* 5 91317-08025 BOLT 3

6 4XV-25832-80 BRACKET, DISK 1

* 7 90149-06286 SCREW 3

* 8 90185-06122 NUT 3

9 4XV-25683-80 SPACER 1

10 4FN-25366-70 CLUTCH, HUB 1

11 4XV-2539F-70 PLATE 1

* 12 91317-10025 BOLT 5

* 13 90185-10037 NUT 5

14 4XV-25376-80 COLLAR, SPROCKET 1

15 4FN-25441-70 Rr. SPROCKET 41T SIZE 520

16 5FL-93306-70 BEARING 1

4FN-25442-70 Rr. SPROCKET 42T SIZE 520

4FN-25443-70 Rr. SPROCKET 43T SIZE 520

4FN-25444-70 Rr. SPROCKET 44T SIZE 520

4FN-25445-70 Rr. SPROCKET 45T SIZE 520

4FN-25446-70 Rr. SPROCKET 46T SIZE 520
