1.2 Rear Panel
ETHERNET
Ethernet Interface. For details on the Ethernet,
see section 9.5 in IM AQ6370E-01EN.
USB interface
Used to connect USB storage media. For details on
the devices, see section 3.3.
VIDEO OUT (XGA)
Analog RGB video signal
interface.
GP-IB
GP-IB port for controlling this unit through an
external computer. For details on the GP-IB,
see chapter 2 in IM AQ6370E-17EN.
TRIGGER IN
Trigger input. For details on the
trigger input, see section 3.4 in
IM AQ6370E-01EN.
ANALOG OUT
Analog output. For details on the analog output,
see section 3.6 in IM AQ6370E-01EN.
TRIGGER OUT
Trigger output. For details on the trigger output, see section
3.5 in IM AQ6370E-01EN.
Exhaust holes
MAIN POWER
Used to turn the main power
ON/OFF. For details on the
Power ON/OFF, see section 3.4.
Power cord connector
Connect the power cord to this
connector. For details on the Power
cord, see section 3.4.
