6.2 External Dimensions
Unit: mm
(approx. inch)
Unless otherwise specified, tolerances are ±3% (however, tolerances are ±0.3 mm when below 10 mm).
426
(16.77)
13
13
(0.51)
19.6 (0.77)
221 (8.70)
(0.59)
15
458.8
(18.06)
32
REAR VIEW
(1.26)
(0.51)
