YOKOGAWA AXW Series Installation Manual

 Process Alarm
The device works normally and some issue of process causes abnormal measurement.
Maintenance work is needed.
NE107
Status
Error Message
Error Description Countermeasure
Display
S 050:Signal overow Failure of input signal was detected. Check signal cable and grounding.
S 051:Empty detect
Empty inside of sensor was detected. (Empty pipe
detection)
Fill ow tube with uid.
N 052:H/L HH/LL alm Flow rate exceeded upper limit or lower limit. Check ow rate and setting value.
S 053:Adh over lv 4
The resistance value of the electrodes exceeded Level 4.
(Adhesion detection of insulation to electrode)
Clean electrodes.
N 364:AI1 HH Alarm High High Alarm has occurred.
Check the AI1 Output.Value (AI1.OUT.VALUE) and configuration of
AI1 Hi Hi Lim (AI1.HI_HI_LIM), AI1 Hi Hi Pri (AI1.HI_HI_PRI).
N 365:AI1 LL Alarm Low Low Alarm has occurred.
Check the AI1 Output.Value (AI1.OUT.VALUE) and configuration of
AI1 Lo Lo Lim (AI1.LO_LO_LIM), AI1 Lo Lo Pri (AI1.LO_LO_PRI).
N 366:AI1 Hi Alarm High Alarm has occurred.
Check the AI1 Output.Value (AI1.OUT.VALUE) and configuration of
AI1 Hi Lim (AI1.HI_LIM), AI1 Hi Pri (AI1.HI_PRI).
N 367:AI1 Lo Alarm Low Alarm has occurred.
Check the AI1 Output.Value (AI1.OUT.VALUE) and configuration of
AI1 Lo Lim (AI1.LO_LIM), AI1 Lo Pri (AI1. LO_PRI).
N 368:AI2 HH Alarm High High Alarm has occurred.
Check the AI2 Output.Value (AI2.OUT.VALUE) and configuration of
AI2 Hi Hi Lim (AI2.HI_HI_LIM), AI2 Hi Hi Pri (AI2.HI_HI_PRI).
N 369:AI2 LL Alarm Low Low Alarm has occurred.
Check the AI2 Output.Value (AI2.OUT.VALUE) and configuration of
AI2 Lo Lo Lim (AI2.LO_LO_LIM), AI2 Lo Lo Pri (AI2.LO_LO_PRI).
N 370:AI2 Hi Alarm High Alarm has occurred.
Check the AI2 Output.Value (AI2.OUT.VALUE) and configuration of
AI2 Hi Lim (AI2.HI_LIM), AI2 Hi Pri (AI2.HI_PRI).
N 371:AI2 Lo Alarm Low Alarm has occurred.
Check the AI2 Output.Value (AI2.OUT.VALUE) and configuration of
AI2 Lo Lim (AI2.LO_LIM), AI2 Lo Pri (AI2. LO_PRI).
N 372:AI3 HH Alarm High High Alarm has occurred.
Check the AI3 Output.Value (AI3.OUT.VALUE) and configuration of
AI3 Hi Hi Lim (AI3.HI_HI_LIM), AI3 Hi Hi Pri (AI3.HI_HI_PRI).
N 373:AI3 LL Alarm Low Low Alarm has occurred.
Check the AI3 Output.Value (AI3.OUT.VALUE) and configuration of
AI3 Lo Lo Lim (AI3.LO_LO_LIM), AI3 Lo Lo Pri (AI3.LO_LO_PRI).
N 374:AI3 Hi Alarm High Alarm has occurred.
Check the AI3 Output.Value (AI3.OUT.VALUE) and configuration of
AI3 Hi Lim (AI3.HI_LIM), AI3 Hi Pri (AI3.HI_PRI).
N 375:AI3 Lo Alarm Low Alarm has occurred.
Check the AI3 Output.Value (AI3.OUT.VALUE) and configuration of
AI3 Lo Lim (AI3.LO_LIM), AI3 Lo Pri (AI3. LO_PRI).
N 392:PID HH Alarm High High Alarm has occurred.
Check the PID Output.Value (PID.OUT.VALUE) and configuration of
PID Hi Hi Lim (PID.HI_HI_LIM), PID Hi Hi Pri (PID.HI_HI_PRI).
N 393:PID LL Alarm Low Low Alarm has occurred.
Check the PID Output.Value (PID.OUT.VALUE) and configuration of
PID Lo Lo Lim (PID.LO_LO_LIM), PID Lo Lo Pri (PID.LO_LO_PRI).
N 394:PID Hi Alarm High Alarm has occurred.
Check the PID Output.Value (PID.OUT.VALUE) and configuration of
PID Hi Lim (PID.HI_LIM), PID Hi Pri (PID.HI_PRI).
N 395:PID Lo Alarm Low Alarm has occurred.
Check the PID Output.Value (PID.OUT.VALUE) and configuration of
PID Lo Lim (PID.LO_LIM), PID Lo Pri (PID.LO_PRI).
<7. Errors and Countermeasures (Display unit)>
64
IM 01E24A01-01EN
