4.35 XY Group
The commands in this group deal with the X-Y waveform display. You can make the same settings and queries that
you can by using Analysis > X-Y in the top menu.
:XY:WAVeform?
Function Queries all X-Y waveform settings.
Syntax
:XY:WAVeform?
:XY:WAVeform:DISPlay
Function Sets or queries whether the specified X-Y
waveform is displayed.
Syntax
:XY:WAVeform:DISPlay {<Boolean>}
:XY:WAVeform:DISPlay?
Example
:XY:WAVEFORM:DISPLAY ON
:XY:WAVEFORM:DISPLAY?
-> :XY:WAVEFORM:DISPLAY 1
:XY:WAVeform:XTRace
Function Sets or queries the channel that is assigned to
the specified X-Y waveform’s X axis.
Syntax
:XY:WAVeform:XTRace {<NRf>[,<NRf>]|
MATH<x>}
:XY:WAVeform:XTRace?
First <NRf> = 1 to 4
Second <NRf> = 1 to 60 (sub channel, depends
on the module)
<x> = 1, 2
Example
:XY:WAVEFORM:XTRACE 1
:XY:WAVEFORM:XTRACE?
-> :XY:WAVEFORM:XTRACE 1
Description You cannot select the channel of a logic module.
:XY:WAVeform:YTRace
Function Sets or queries the channel that is assigned to
the specified X-Y waveform’s Y axis.
Syntax
:XY:WAVeform:YTRace {<NRf>[,<NRf>]|
MATH<x>}
:XY:WAVeform:YTRace?
First <NRf> = 1 to 4
Second <NRf> = 1 to 60 (sub channel, depends
on the module)
<x> = 1, 2
Example
:XY:WAVEFORM:YTRACE 2
:XY:WAVEFORM:YTRACE?
-> :XY:WAVEFORM:YTRACE 2
Description You cannot select the channel of a logic module.
:XY?
Function Queries all X-Y waveform display settings.
Syntax
:XY?
:XY:DOTConnect
Function Sets or queries whether dot connect is ON or
OFF for X-Y waveforms.
Syntax
:XY:DOTConnect {<Boolean>}
:XY:DOTConnect?
Example
:XY:DOTCONNECT ON
:XY:DOTCONNECT? -> :XY:DOTCONNECT 1
:XY:DECimation
Function Sets or queries the number of dots that X-Y
waveforms use.
Syntax
:XY:DECimation {<NRf>}
:XY:DECimation?
<NRf> = 2000, 100000
Example
:XY:DECIMATION 2000
:XY:DECIMATION?
-> :XY:DECIMATION 2000
:XY:MARKer
Function Sets or queries whether X-Y pen markers are on.
Syntax
:XY:MARKer {<Boolean>}
:XY:MARKer?
Example
:XY:MARKER ON
:XY:MARKER? -> :XY:MARKER 1
:XY:TCLear (Trace Clear On Start)
Function Sets or queries whether the X-Y waveform trace-
clear-on-start feature is on.
Syntax
:XY:TCLear {<Boolean>}
:XY:TCLear?
Example
:XY:TCLEAR ON
:XY:TCLEAR? -> :XY:TCLEAR 1
