4-173
IM DL350-17EN
Commands
1
2
3
4
5
App
Index
4.36 ZOOM Group
The commands in this group deal with the zoomed display. You can make the same settings and queries that you can
by using Analysis > Zoom in the top menu.
If the selectable range of the time axis is “<NRf> = –5 to 5div,” the selectable range varies depending on settings such
as the record length.
For details, see “Selectable Range of Cursor Positions” under “Notes about Cursor Measurement” in chapter 9 of IM
DL350-01EN.
:ZOOM:FITMeasure
Function Moves the range on which automated
measurement of waveform parameters is
performed to the zoom waveform display frame.
Syntax
:ZOOM:FITMeasure {Z1|Z2}
Example
:ZOOM:FITMEASURE Z1
:ZOOM:FORMat<x>
Function Sets or queries the display format of the specified
zoom waveform.
Syntax
:ZOOM:FORMat<x> {MAIN|<NRf>}
:ZOOM:FORMat<x>?
<NRf> = 1, 2, 3, 4, 5, 6, 8, 12, 16
<x> = 1, 2 (sets the target zoom box)
Example
:ZOOM:FORMAT1 1
:ZOOM:FORMAT1? -> :ZOOM:FORMAT1 1
:ZOOM:GROup<x1>?
Function Queries all settings related to the specified group
display of zoom waveforms.
Syntax
:ZOOM:GROup<x1>?
:ZOOM:GROUp<x1>:FORMat<x2>
Function Sets or queries the zoom waveform display
format of the specified display group.
Syntax
:ZOOM:GROUp<x1>:FORMat<x2> {MAIN|
<NRf>}
:ZOOM:GROUp<x1>:FORMat<x2>?
<NRf> = 1, 2, 3, 4, 5, 6, 8, 12, 16
<x1> = 1 to 4
<x2> = 1, 2 (sets the target zoom box)
Example
:ZOOM:GROUP1:FORMAT1 1
:ZOOM:GROUP1:FORMAT1?
-> :ZOOM:GROUP1:FORMAT1 1
:ZOOM:GROup<x1>:TRACe<x2>
Function Sets or queries whether the specified source
waveform of the specified group display of zoom
waveforms is displayed.
Syntax
:ZOOM:GROup<x1>:
TRACe<x2> {<Boolean>}
:ZOOM:GROup<x1>:TRACe<x2>?
<X1> = 1 to 4 (sets the group display)
<x2> = 1 to 32 (sets the source waveform)
Example
:ZOOM:GROUP1:TRACE1 1
:ZOOM:GROUP1:TRACE1?
-> :ZOOM:GROUP1:TRACE1 1
Description Zoom1 and Zoom2 both reference the same
setting.
:ZOOM?
Function Queries all zoom settings.
Syntax
:ZOOM?
:ZOOM:ASCRoll?
Function Queries all auto scroll settings.
Syntax
:ZOOM:ASCRoll?
:ZOOM:ASCRoll:JUMP
Function Moves the center position of the zoom box to the
left or right edge of the main window.
Syntax
:ZOOM:ASCRoll:JUMP {LEFT|RIGHt}
Example
:ZOOM:ASCROLL:JUMP RIGHT
:ZOOM:ASCRoll:SPEed
Function Sets or queries the auto scroll speed of the zoom
box.
Syntax
:ZOOM:ASCRoll:SPEed {<NRf>}
:ZOOM:ASCRoll:SPEed?
<NRf> = 1 to 10
Example
:ZOOM:ASCROLL:SPEED 5
:ZOOM:ASCROLL:SPEED?
-> :ZOOM:ASCROLL:SPEED 5
:ZOOM:ASCRoll:STARt
Function Starts auto scrolling.
Syntax
:ZOOM:ASCRoll:STARt {LEFT|RIGHt}
Example
:ZOOM:ASCROLL:STAR LEFT
:ZOOM:ASCRoll:STOP
Function Stops auto scrolling.
Syntax
:ZOOM:ASCRoll:STOP
Example
:ZOOM:ASCROLL:STOP
:ZOOM:ASCRoll:TARGet
Function Sets or queries the zoom window that will be auto
scrolled.
Syntax
:ZOOM:ASCRoll:TARGet {Z1|Z2}
:ZOOM:ASCRoll:TARGet?
Example
:ZOOM:ASCROLL:TARGET Z1
:ZOOM:ASCROLL:TARGET?
-> :ZOOM:ASCROLL:TARGET Z1
