YOKOGAWA FLXA21

27
IM 12A01A02-12E 9th Edition : Mar. 23, 2018-00
(Note) The universal mounting kit (/UM) contains the pipe and wall mounting hardware (/U) and the panel
mounting hardware (/PM).
Panel mounting hardware (Option code: /PM, /UM)
2-M5 length 35
185
178
100
195
135
Panel thickness
1 to 12
Spacing panel cutout
4-M6 *
138
+1
0
138
+1
0
FB4_03.ai
Unit: mm
*: Tighten the four screws to a torque of 2 N•m.
Wall mounting hardware (Option code: /U, /UM)
144
164
13
100
70
144
224
200
50
15
For wall mounting
3-ø10 holes
4-M6 *
FB4_02.ai
Unit: mm
*: Tighten the four screws to a torque of 2 N•m.
Note: The wall on which the analyzer is mounted should be strong enough to bear the weight of more than 8 kg.
Pipe mounting hardware (Option code: /U, /UM)
151
100
200
50 174
144
(205)
Pipe mounting (Horizontal)
Pipe mounting (Vertical)
Pipe 50A
(ø60.5)
M8 U-bolt
4-M6 *
FB4_04.ai
Unit: mm
*: Tighten the four screws to a torque of 2 N•m.
