7-20 IM 04L20A01-01E
7.8 Clearing the Data in the Internal Memory
This section explains how to clear all the data in the internal memory including display
data, event data, manual sample data, TLOG data (/M1, /PM1 option), and report
data (/M1, /PM1 option). To clear the log information in addition to the above data,
perform the procedure for clearing the internal memory in basic setting mode (see
section 3.5).
Clearing the Data in the Internal Memory <Setting Mode>
Procedure
Opening the Operation Dialog Box
MENU key (switch to setting mode) > #7 soft key (select [Save/Load, Clear data]) >
#9 (or #1
*
) soft key (select [Clear data])
* For models with no external storage drive.
From the operation display, use the above keys to open the following dialog box.
Operations on the Display
Select [Yes] and press the DISP/ENTER key.
The data is cleared. To cancel the operation, select [No] using the right arrow key
and press the DISP/ENTER key.
Note
The data acquired in the internal memory is also cleared when memory-related settings are
changed in basic setting mode. In this case, the following confirmation dialog box appears.
To Next Page
