YOKOGAWA FX112 - #11 Math set3 (Tag, TLOG, Rolling average, Alarm delay time) (M1 or PM1 option)

App-29
IM 04L20A01-01E
App
Appendix
#11 Math set3 (Tag, TLOG, Rolling average, Alarm delay time) (/M1 or /PM1 option)
Parameter Selectable Range or Selections Initial Value
First-CH 31 to 42 31
Last-CH 31 to 42 31
Tag > Tag Up to 16 alphanumeric characters –
TLOG > Timer No. 1, 2, or 3 1
TLOG > Sum scale Off, /s, /min, or /h Off
Rolling average On/Off Off
Rolling average > Interval 1 s, 2 s, 3 s, 4 s, 5 s, 6 s, 10 s, 12s, 15s, 20s, 30s, 10 s
1 min, 2 min, 3 min, 4 min, 5 min, 6 min, 10 min, 12 min,
15 min, 20 min, 30 min, or 1 h
Rolling average > Number of samples 1 to 250 1
Alarm delay time 1 s to 3600 s 10 s
Appendix 6 List of Parameters
