YOKOGAWA GX60 User Manual

1-129
IM 04L51B01-01EN
Configuring the GX/GP
1
2
3
4
5
App
Index
Options Description
Adjust the time Sets the clock to the nearest hour.
Relay Set the relay output to On or Off.
Internal switch Set the internal switch to On or Off.
WhentheEventOperationModeIsRising/FallingEdge
Options Description
Recording start/stop Repeats recording start and stop on every event occurrence.
Computation start/stop Repeats computation (/MT option) start and stop on every event
occurrence.
Switch the display rate 1, 2 Switches the display rate on every event occurrence.
Flag On/Off Repeats the operation of setting the flag to 1 (On) and 0 (Off) on every
event occurrence.
Relay On/Off Repeats the operation of setting the relay to On and Off on every event
occurrence.
Internal switch On/Off Repeats the operation of setting the internal switch to On and Off on
every event occurrence.
Detail
Set the details when the action type is set to Recorded, Computation, or Message.
When Set to Recorded or Computation
Options Description
Start Starts recording or computation.
Stop Stops recording or computation.
Reset (Computation only) Resets computation.
When Set to Message
Options Description
All groups Writes the message to all groups.
Specified group Writes the message to the specified group. Set the destination by
specifying a group number.
WhenSettoRelayorInternalswitch
Options Description
On Sets to On.
Off Sets to Off.
Note
Do not manually operate a relay assigned to a status event or the output status of an internal
switch action.
1.15ConfiguringtheEventActionFunction
