YOKOGAWA GX60 User Manual

1-130
IM 04L51B01-01EN
Number
Set the target number for Message, Show the specified display, Reset the relative timer,
Switch the display group, Event trigger, Save event data, Flag, or Switch the display rate,
user function key.
Operation mode Type Setup Item
Rising edge,
Falling edge
Switch the display rate Display rate number (First, Second)
Flag Flag number 1 to 20
Save event data Scan group 1
Event trigger Scan group 1
Message Message number 1 to 100
Switch the display group Display Group
GX20/GP20: 1 to 50
GX20-2/GP20-2: 1 to 60
GX10/GP10: 1 to 30
When the multi-batch function (/BT option) is
enabled
GX10/GP10/GX20-1/GP20-1: 1 to 6
GX20-2/GP20-2: 1 to 12
Reset the relative timer Timer number 1 to 12 (relative time)
Show the favorite display Screen number 1 to 20
Load settings Load number 1 to 10
Rising / Falling edge Flag On/Off Flag number 1 to 20
Group number
Set the display group number to write the message to when Specified group is specified.
Batch group number
When the multi-batch function (/BT option) is enabled, set the batch group on which to
execute the action.
Options Description
All Specifies all batch groups.
However, this is available only when the type is set to
Recorded, Computation, Save display data, or Save event data.
However, for Computation, the detail must be set to Reset.
GX10/GP10/GX20-1/GP20-1: 1 to 6
GX20-2/GP20-2: 1 to 12
Specifies a batch group.
1.15ConfiguringtheEventActionFunction
