YOKOGAWA GX60 User Manual

General
Specications
GX10/GX20
Paperless Recorder
(Panel mount type)
Yokogawa Electric Corporation
2-9-32, Nakacho, Musashino-shi, Tokyo, 180-8750 Japan
GS 04L51B01-01EN
GS 04L51B01-01EN
©Copyright November 2012
13th Edition Nov. 10, 2015
 OVERVIEW
The GX10/GX20 are paperless recorders that display
real-time measured data on a touch screen and save
data on an external storage medium (SD card).
For the input/output module specication, please see
GX90XA/GX90XD/GX90YD/GX90WD/GX90XP Input/
Output Module General Specication (GS 04L53B01-
01EN.)
● Thenumberofanaloginputisamaximumof100
channelsinGX10withexpandableI/O,amaximum
of100channelsinGX20standardtype(hereafter
referredtoas“GX20-1”)withexpandableI/O,anda
maximumof450*channelsinGX20largememory
type(hereafterreferredtoas“GX20-2”)with
expandableI/O.
*Max.numberofinput/outputchannelsis500channels.
● TheGX10/GX20havethelargeinternalmemory
(GX10/GX20-1: 500MB, GX20-2: 1.2 GB), and
prolonged record and preservation are possible.
● Astheinputsignal,aDCvoltage,thermocouple,
resistancetemperaturedetector,DI(DCVinput
(TTL),contactsignal),mA(DCcurrent),orPulse
input can be set to each channel.
● Inputandoutputhavemodulestructureanditcan
extendthemeasily.(GX10:max.3*,GX20:max.10*)
* IncaseofusingexpandableI/O,GX10can
extendtwounits,GX20canextend9units.
● Amoduletypeisvetypes,ananaloginput,a
digital input, a digital output, a digital input/output,
and a pulse input.
● AmaximumofsixunitsofexpandableI/Ocanbe
connectedtoGX10/GX20.EachexpandableI/O
canincorporateamaximumofsixmodules.With
expandableI/Oconnected,GX10andthelarge
memory type GX20 can use multiple channels.
Furthermore,theI/Oportscanbeinstalledin
separatelocationsfromwhereGX10/GX20is
located, helping you reduce wiring requirements
andbuildadecentralizedconguration.
● Theintuitiveoperationbyick,pinchin,andpinch
out are possible.
● Thepasttrendunderrecordingcanbeseamlessly
displayed on a trend screen.
● Moreover,themeasurementdataofthetime
speciedonthecalendarscreencanbesearched
and displayed.
● Variousfunctions,suchasafreehandmessage,
aPDF/Exceloutputofareportle,adirectoutput
toanetworkprinter,ascalemovementofatrend
display, and a buzzer, are equipped.
● ItcanbehookeduptonetworkviaEthernet,which
enablestoinformbyEmailandtomonitoronWeb
siteaswellastotransferlesbyusingFTP.Also,
it can communicate with Modbus/RTU or Modbus/
TCP.
● AsetupofGXcanbeperformedon-linefromthe
webbrowseronPC.Asetupbyoff-lineisalso
possible.
● UniversalViewersoftwareallowsaPCto
displaywaveformsonitsscreenandtoprintout
waveforms.
● Themeasuringaccuraciesnotedinthegeneral
specicationshaveamarginoferrorthattakes
into account the product's components and the
equipmentusedforadjustmentandtesting.
However,theactualvaluescalculatedfromthe
accuracytestingdatauponshipmentofthe
instrumentfromthefactoryareasfollows.
Inputtype Measuring accuracy
*1
(typical value
*2
)
DCV 20mV ±(0.01%ofrdg+5μV)
60mV ±(0.01%ofrdg+5μV)
6 V (1-5 V)
±(0.01%ofrdg+2mV)
TC
*3
R
± 1.1°C
K
±(0.01%ofrdg+0.2°C)for0.0
to 1370.0 °C;
±(0.15%ofrdg+0.2°C)for
-200.0 to 0.0 °C
K (-200 to 500
°C
)
±0.2°Cfor0.0to500.0°C;
±(0.15%ofrdg+0.2°C)for
-200.0 to 0.0 °C)
J
±0.2°Cfor0.0to1100.0°C;
±(0.10%ofrdg+0.2°C)for
-200.0 to 0.0 °C
T
±0.2°Cfor0.0to400.0°C;
±(0.10%ofrdg+0.2°C)for
-200.0 to 0.0 °C
N
±(0.01%ofrdg+0.2°C)for0.0
to 1300.0°C;
±(0.22%ofrdg+0.2°C)for
-200.0 to 0.0 °C
RTD Pt100 ±(0.02%ofrdg+0.2°C )
Pt100
(high resolution)
±(0.02%ofrdg+0.16°C)
GX10 GX20
