3. Cabling
3-16
TI 32P01J10-01EN
An example of installing a node unit in a general-purpose cabinet along with an AEP7D Primary
Power Supply Bus Unit is shown.
F030410.ai
General-purpose Cabinet
SNB10D
L
N
L
N
TM2
100-120V AC,
TM1
100-120V AC,
AEP7D
SNB10D
Functional grounding
Protective grounding
system
Figure Example of Installing AEP7D in a General-purpose Cabinet (Dual AC Power Supply Line)
Nov. 27, 2015-00
