3. Cabling
3-17
TI 32P01J10-01EN
SNT10D Unit for Optical Bus Repeater Module
L
N
Cover
F030411.ai
Power supply module
Power supply
input terminal
Functional grounding
terminal
(Terminal screw: M4)
Functional grounding terminal
(Terminal screw: M4)
IO1 IO2 IO3 IO4 IO5 IO6 IO7 IO8 B1 B2
Figure SNT10D Power Cable Connection
Oct. 25, 2016-00
