3. Cabling
3-34
TI 32P01J10-01EN
Pressure Clamp Terminal (for Pressure Clamp Terminal Block) (for terminal
block, terminal board, and relay board)
• Terminal processing
When connecting the process I/O signal to the pressure clamp terminal of an I/O module,
strip the cable coating (without a sleeve) or attach a sleeve to the cable. The following
shows the length of the coating stripped for cases when a sleeve is not used and when it is
used.
SBT4D, STA4S, STA4D, STB4S, and STB4D
Table Without a Sleeve
Cable thickness Peel-o Length
0.5 mm
2
to 2 mm
2
(AWG20 to 14) 11 mm
Table With a Sleeve
Cable
thickness
When using a sleeve with an insulating cover
When using a sleeve without
insulating cover
Peel-o
Length
Sleeve dimensions
Weidmuller
Model No.
Peel-o
Length
Sleeve
dimensions
Weidmuller
Model No.
Total
length
Contact
section length
Total length
0.5 mm
2
11 mm 16 mm 10 mm H0.5/16 11 mm 10 mm H0.5/10
0.75 mm
2
11 mm 16 mm 10 mm H0.75/16 11 mm 10 mm H0.75/10
1 mm
2
11 mm 16 mm 10 mm H1/16 11 mm 10 mm H1/10
1.25 to
1.5 mm
2
11 mm 16 mm 10 mm H1.5/16 11 mm 10 mm H1.5/10
A2BM4, SBR4D, SBA4D, SBD2D, SBD3D, SBD4D, SBM54D, and S1BB4D
Table Without a Sleeve
Cable thickness Peel-o Length
0.5 mm
2
to 2.5 mm
2
(AWG20 to 14) 8 mm
Table With a Sleeve
Cable
thickness
When using a sleeve with an insulating cover
When using a sleeve without
insulating cover
Peel-o
Length
Sleeve dimensions
Weidmuller
Model No.
Peel-o
Length
Sleeve
dimensions
Weidmuller
Model No.
Total
length
Contact
section length
Total length
0.5 mm
2
10 mm 14 mm 8 mm H0.5/14 6 mm 6 mm H0.5/6
0.75 mm
2
10 mm 14 mm 8 mm H0.75/14 6 mm 6 mm H0.75/6
1 mm
2
10 mm 14 mm 8 mm H1/14 6 mm 6 mm H1/6
1.5 mm
2
10 mm 14 mm 8 mm H1.5/14 7 mm 7 mm H1.5/7
2.5 mm
2
11 mm 14 mm 8 mm H2.5/14D 7 mm 7 mm H2.5/7
Oct. 5, 2018-00
