3. Cabling

3-42

TI 32P01J10-01EN

Mar. 15, 2018-00

 Example of Node Interface Unit and I/O Unit cable wiring (Cabinet)

NIU

F030511.ai

Cable for field power supply

F-SB bus cable

Optical ESB

bus cable

Power Supply

Cable for Base Plate

Cabinet

Power Supply

Cable

Field

Power Supply

: System Wiring Area

From NIU

Figure Example of Node Interface Unit and I/O Unit Cable Wiring (Cabinet)
