YOKOGAWA ProSafe-RS

3. Cabling
3-56
TI 32P01J10-01EN
Example of Connection to SBD2D
SBD2D terminal board allows SDV521 modules in both single and dual-redundant
congurations.
AKB651
Yokogawa-
specific
cable
CN1
CN2
POWER1
POWER2
FUSE1
250V T 15A
FUSE2
250V T 15A
READY
1A 1B 2A 2B 3A 3B 4A 4B
SDV521 (Digital Output Modules)
F030610.ai
SBD2D
Connection with functional
grounding terminal
Figure Connecting Digital Output Modules to SBD2D Terminal Board (for Dual-redundant Use)
Nov. 27, 2015-00
