3. Cabling
3-77
TI 32P01J10-01EN
Cabling for AVR10D System
F030803.ai
Cabinet support
Cabinet support
Tie wrap
Tie wrap
V net cables
Vnet/IP cables
Power supply cables
Grounding cables
VC401
(V net coupler modules)
Use a tie wrap to fix the V net cable onto the support on the side of the VC401.
Figure Cabling Diagram for the AVR10D System
