YOKOGAWA ProSafe-RS User Manual

  4.InstallationSpecications
4-3
TI 32P01J10-01EN
 In-Rush Current for Each Component
Actual in-rush current data measured for each ProSafe-RS component is listed below.
Table System Equipment Power-On In-Rush Current
Equipment
In-rush current (A)
100 V AC
In-rush current (A)
220 V AC
In-rush current (A)
24 V DC
Primary Secondary Primary Secondary Primary Secondary
SSC60S-S Safety Control Unit 62 5 124 5 30 23
SSC60S-F Safety Control Unit
(Wide range temperature type)
82 9 168 8 40 23
SSC60D-S
Duplexed Safety Control Unit
62 5 124 5 30 23
SSC60D-F
Duplexed Safety Control Unit
(Wide range temperature type)
82 9 168 8 30 23
SSC50S-S Safety Control Unit 62 5 124 5 30 23
SSC50S-F Safety Control Unit
(Wide range temperature type)
82 9 168 8 40 23
SSC50D-S
Duplexed Safety Control Unit
62 5 124 5 30 23
SSC50D-F
Duplexed Safety Control Unit
(Wide range temperature type)
82 9 168 8 30 23
SSC57S-S Safety Control Unit 62 5 124 5 30 23
SSC57S-F Safety Control Unit
(Wide range temperature type)
82 9 168 8 40 23
SSC57D-S
Duplexed Safety Control Unit
62 5 124 5 30 23
SSC57D-F
Duplexed Safety Control Unit
(Wide range temperature type)
82 9 168 8 30 23
S2SC70S-S Safety Control Unit 62 5 124 5 30 23
S2SC70S-F Safety Control Unit
(Wide range temperature type)
82 9 168 8 40 23
S2SC70D-S
Duplexed Safety Control Unit
62 5 124 5 30 23
S2SC70D-F
Duplexed Safety Control Unit
(Wide range temperature type)
82 9 168 8 30 23
SNB10D Safety Node Unit 62 5 124 5 30 23
SNT10D Unit for Optical Bus
Repeater Module
62 5 124 5 30 23
AVR10D Duplexed V net router 47 1 48 0.5 10 2
AW810D
Wide Area Communication Router
47 1 48 0.5 10 2
S2NN30D Node Interface Unit 40 — 80 — 60 —
Input current peak values and waveforms, inuenced by input impedance, vary with system
congurations, line sharing with other systems, and other factors. The rush current data shown
above have been measured under the predetermined conditions (see below). Please note that
the values are subject to change.
The power input circuit, with an in-rush current limiting circuit, restrains primary in-rush current,
turning any current exceeding the limits to secondary and successive rush current.
Nov. 27, 2015-00
