YOKOGAWA ProSafe-RS

1. System Installation Requirements
1-8
TI 32P01J10-01EN
 Conformity Standards
The ProSafe-RS complies with the standards shown below.
IMPORTANT
Di󰀨erent standards are applied according to the types of equipment.
For details, refer to GS 32P01B60-01EN “ProSafe-RS Standards Compliant Models”.
 Functional Safety Standards
IEC 61508, IEC 61511-1 and IEC 62061
 Programmable Controllers Standards (*1), (*2), (*3)
IEC 61131-2
 Application Standards (*1)
EN 54-2 (*2), EN 298 (*3), (*4), EN 50156-1, NFPA 72, NFPA 85, and NFPA86
 Safety Standards (*5), (*6), (*7), (*8)
[CSA]
CAN/CSA-C22.2 No.61010-1, CAN/CSA-IEC 61010-2-201, CAN/CSA-C22.2 No.61010-2-030
[CE Marking] Low Voltage Directive
EN 61010-1, EN 61010-2-201, EN 61010-2-030, EN 60825-1
[EAC Marking]
CU TR 004
*1: Except for the case of using S2BN1D, S2BN4D, and S2BN5D in combination with S2MMM843 or S2MDV843 of style S2 or later,
a lightning arrester or the like is required to meet this surge immunity standard.
*2: 24 V DC and 48 V DC eld power to DI and DO shall not be provided directly from a DC distribution network. The eld power
supply cable length must be 30 m or less.
*3: Where the system power uses 24 V DC (SPW484), use an external uninterruptible power supply (UPS).
*4: 24 V DC and 48 V DC eld power to DI and DO shall not be provided directly from a DC distribution network. The eld power
supply cable length must be 10 m or less.
*5: For the rack mountable devices, DIN rail mountable devices, and wall mountable devices to meet the Safety Standards and EMC
Standards, the devices must be installed in a lockable metal cabinet. The cabinet must conform to IEC/EN/CSA 61010-2-201 or
provide degrees of protection IP3X or above and IK09 or above.
*6: ProSafe-RS measurement input corresponds to the measurement category O (Other) based on IEC/EN 61010-2-030 and CAN/
CSA-C 22.2 No. 61010-2-030. The measurement category I dened in IEC/EN 61010-1: 2001 and CAN/CSA-C 22.2 No. 61010-
1-04 has been changed to O (Other).
*7: For ensuring all the hardware devices to satisfy the safety standards, the dedicated breakers in the power supply distribution
board must conform to the following specications.
[CSA] CSA C22.2 No.5 or UL 489
[CE Marking] EN 60947-1 and EN 60947-3
[EAC Marking] EN 60947-1 and EN 60947-3
*8: The ground suitable for the power distribution system in the country or region has to be used for protective grounding system.
Mar. 29, 2019-00
