1. System Installation Requirements
1-9
TI 32P01J10-01EN
EMC Conformity Standards (*1), (*2), (*3)
[CE Marking] EMC Directive
EN 55011 Class A Group1 (*4)
EN 61000-6-2
EN 61000-3-2 (*5)
EN 61000-3-3
EN 61326-1 (*6)
[RCM]
EN 55011 Class A Group1 (*4)
[KC Marking]
Korea Electromagnetic Conformity Standard
[EAC Marking]
CU TR 020
[Functional Safety]
IEC 61326-3-1 (*6) (*7)
*1: Except for the case of using S2BN1D, S2BN4D, S2BN5D, S2NN70D, and S2NN60D in combination with S2MMM843 or
S2MDV843 of style S2 or later, a lightning arrester or the like is required to meet this surge immunity standard.
*2: 24 V DC and 48 V DC eld power to DI and DO shall not be provided directly from a DC distribution network. The eld power
supply cable length must be 30 m or less.
*3: For the rack mountable devices, DIN rail mountable devices, and wall mountable devices to meet the Safety Standards and EMC
Standards, the devices must be installed in a lockable metal cabinet. The cabinet must conform to IEC/EN/CSA 61010-2-201 or
provide degrees of protection IP3X or above and IK09 or above.
*4: A Class A hardware device is designed for use in the industrial environment. Please use this device in the industrial environment
only.
*5: An external device such as a power unit with harmonic current neutralizer and an active harmonics conditioner must be
connected to meet this harmonic current emission standard. See Section 1.3 “Power Supply System”.
*6: The base plate for barrier S2BN4D and S2BN5D conforms to the EMC standards with conditions. For details, refer to GS
32P06P10-01EN “Base Plates for Barrier (for N-IO)”.
*7: Where the system power uses 24 V DC (S2PW504), use an external uninterruptible power supply (UPS).
Standard for Hazardous (Classied) Locations
[ATEX Type “n”]
[IECEx Type “n”]
[Canada (FM) Non-Incendive]
[US (FM) Non-Incendive]
SEE
ALSO
For more information about Standard for Hazardous Locations, refer to TI 32S01J30-01E “Explosion Protection
(for ProSafe-RS).”
Marine Standards
ABS (American Bureau of Shipping)
BV (Bureau Veritas)
LR (Lloyd’s Register)
DNV GL
SEE
ALSO
For more information about the components which comply with the marine standards and how to install those
components, refer to 1.8, “Compliance with Marine Standards.”
In relation to the CE Marking, the manufacturer and the authorised representative for ProSafe-
RS in the EEA are indicated below:
Manufacturer: YOKOGAWA Electric Corporation
(2-9-32 Nakacho, Musashino-shi, Tokyo 180-8750, Japan.)
Authorised representative in the EEA: Yokogawa Europe B.V.
(Euroweg 2, 3825 HD Amersfoort, The Netherlands.)
Jan. 21, 2019-00
